Our company “GLOBAL BUILDING” is a manufacturer of modern, modular ventilation blocks that provide a simple and effective solution for ventilation systems in multi-apartment buildings.

Our advantages

individual approach

production and calculation our products to your order

installation of our products (possible at any stage building construction)

license for assembly types of work

installing with adhesive mixture

the variety of block dimensions allows for economical integration into walls

fast delivery and manufacturing

quality certificate

The company “GLOBAL BUILDING” was founded in 2017 and continues to develop dynamically. Over the years of our work, we have proven ourselves as a reliable partner, offering high-quality products with a large assortment of modular blocks, fast production times, and additional services for their installation.

Schematic diagram
of a fragment of the plan

Schematic comparison
of two ventilation systems

vent 910×400

Dimensions, mm: 910x400x200
Channel size, mm:
collector: 320×670
satellite: 320×120

vent(3) 910×400

Dimensions, mm: 910x400x200
Channel size, mm:
collector: 320×235
satellite: 320×120

vent 910×300

Dimensions, mm: 910x300x200
Channel size, mm:
collector: 220×670
satellite: 220×120

vent(2) 910×300

Dimensions, mm: 910x300x200
Channel size, mm:
collector: 220×510
satellite: 220×120

vent 910×250

Dimensions, mm: 910x250x200
Channel size, mm:
collector: 170×670
satellite: 170×120

vent-3t 910×250

Dimensions, mm: 910x250x200
Channel size, mm:
collector: 170×250

vent(2) 800×400

Dimensions, mm: 800x400x200
Channel size, mm:
collector: 320×400
satellite: 320×120

vent 800×400

Dimensions, mm: 800x400x200
Channel size, mm:
collector: 320×560
satellite: 320×120

vent(2с) 800×400

Dimensions, mm: 800x400x200
Channel size, mm:
collector: 320×560
satellite: 140×120

vent 800×300

Dimensions, mm: 800x300x200
Channel size, mm:
collector: 220×560
satellite: 220×120

vent-2t 630×300

Dimensions, mm: 630x300x200
Channel size, mm:
collector: 310×220

vent 630×300

Dimensions, mm: 630x300x200
Channel size, mm:
collector: 220×390
satellite: 220×120

vent-d 550×550

Dimensions, mm: 550x550x200
Channel size, mm:
collector: 450×450

vent 550×400

Dimensions, mm: 550x400x200
Channel size, mm:
collector: 320×310
satellite: 320×120

vent 520×250

Dimensions, mm: 520x250x200
Channel size, mm:
collector: 170×120

vent-d 480×480

Dimensions, mm: 480x480x200
Channel size, mm:
collector: 380×380

vent 480×400

Dimensions, mm: 480x400x200
Channel size, mm:
collector: 320×240
satellite: 320×120

vent-d 400×400

Dimensions, mm: 400x400x200
Channel size, mm:
collector: 320×320

vent 360×250

Dimensions, mm: 360x250x200
Channel size, mm:
collector: 170×120

vent 200×250

Dimensions, mm: 250x200x200
Channel size, mm:
collector: 170×120

Detailed size chart

Coaxial systems are used in cases where it is necessary to reduce the weight of the system and the load on the foundation. And also when it is necessary to shorten the time of installation works

Pipe

The main element of DSPG
L = 1000, 500, 300
The seal is not included in the package

Stand

Performs the function of a condensate collector

Checkup

It is used for inspection and cleaning of the chimney

Pipe

The main element of DSPG
L = 1000, 500, 300
The seal is not included in the package

Stand

Performs the function of a condensate collector

Inspection with a through hole

It is used for inspection and cleaning of the chimney

Tee is coaxial

is used to connect heat generators to DSPG

Coaxial shaft cover

It is used for joint emission of gases and air collection.

The outer shell of the system is made of concrete blocks of factory production, which excludes violations of the calculated parameters of the system during installation. The inner pipe of the DSPG is made of acid-resistant stainless steel, insensitive to the action of condensate. Thanks to this, the life of the chimney is actually equal to the life of the building.
